Note 1) The photo shows the appearance of NZ2WL-JPA. Products with the above model numbers have the same appearance as the NZ2WL-JPA.
Note 2) In Japan, it is a dedicated device for access points and stations.
Overseas, it is a device that doubles as an access point and station. Change the settings to suit your needs.

item			specification
Wired LAN part ^{* 1, 2}	interface		IEEE802.3u (100BASE-TX) /IEEE802.3 (10BASE-T)
	Data transfer rate		10Mbps / 100Mbps
	Communication method		Full duplex / half duplex
	Number of ports		1
Wireless LAN part ^{* 3}	IEEE 802.11a	Transmission format	IEEE 802.11a compliant OFDM (Orthogonal Frequency Division Multiplexing) system
	IEEE 802.11a	Data transfer speed ^{* 4}	54, 48, 36, 24, 18, 12, 9, 6Mbps (fixed / automatic)
	IEEE 802.11b	Transmission format	IEEE802.11b compliant DSSS method
	IEEE 802.11b	Data transfer speed ^{* 4}	11, 5.5, 2, 1Mbps (fixed / automatic)
	IEEE 802.11g	Transmission format	IEEE 802.11g compliant OFDM (Orthogonal Frequency Division Multiplexing) system
	IEEE 802.11g	Data transfer speed ^{* 4}	54, 48, 36, 24, 18, 12, 9, 6Mbps (fixed / automatic)
	channel		It depends on the country of use. Please refer to the user's manual of the product.
	Security		WEP, WPA-PSK (AES, TKIP), WPA2-PSK (AES, TKIP), AES-OCB, WSL (can be used with encryption other than WSL) AP only: WPA (AES, TKIP), WPA2 (AES, TKIP) , MAC address filtering, IEEE802.1X (EAP-TLS, PEAP)

* 1) For connectable products and usage precautions, refer to the user's manual of the product.
* 2) Not applicable to the Web server unit (QJ71WS96).
* 3) We do not guarantee mutual connection with other Wi-Fi compatible products.
* 4) This is a theoretical value of the wireless LAN standard and does not indicate the actual data transfer rate.

Products with the indications on the left are jointly developed and manufactured by Contec Co., Ltd. and our company.
Please note that the general specifications and warranty details differ from our products.
